10T C Frame hydraulic presses for sale.
With a wide range of available accessories such as die cushions and
automatic die change systems, these press solutions can quickly
boost the productivity of any workshop.
Furthermore, all our C-Frame hydraulic press machines and high
speed press machines are designed with a highly rigid structure and
uneven loading resistance for long lasting precision.
By always understanding our customers’ requirements and designing
machines in cooperation with them, MEILI is able to design high
precision presses that perform at the highest level, day in day
out.
| Description | Unit | 4T | 6.3T | 10T | 16T | 25T | 40T | 63T | 100T | 160T | 200T | 250T | 315T |
| Nominal Force | KN | 40 | 63 | 100 | 160 | 250 | 400 | 630 | 1000 | 1600 | 2000 | 2500 | 3150 |
| Max pressure of liquid | Mpa | 8 | 8 | 8 | 13 | 20 | 22 | 25 | 25 | 25 | 25 | 25 | 25 |
| Max opening height | mm | 400 | 450 | 500 | 550 | 600 | 700 | 800 | 800 | 800 | 800 | 800 | 900 |
| Max stroke of slider | mm | 200 | 250 | 300 | 350 | 350 | 400 | 500 | 500 | 500 | 500 | 500 | 500 |
| Down speed of slider | mm/s | 42 | 42 | 42 | 42 | 42 | 42 | 42 | 35 | 30 | 35 | 30 | 30 |
| Return speed of slider | mm/s | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 60 | 60 | 65 | 60 | 55 |
| Throat Depth | mm | 180 | 250 | 250 | 280 | 280 | 300 | 300 | 320 | 320 | 320 | 320 | 400 |
| Table size | L-R | mm | 400 | 480 | 480 | 600 | 600 | 600 | 700 | 800 | 800 | 900 | 900 | 1000 |
| F-B | mm | 320 | 440 | 440 | 500 | 500 | 550 | 600 | 600 | 650 | 650 | 650 | 700 |
| Operation Height | mm | 710 | 710 | 710 | 710 | 710 | 710 | 710 | 710 | 710 | 710 | 710 | 710 |
| Blanking aperture | mm | 50 | 50 | 50 | 50 | 60 | 80 | 80 | 80 | 100 | 100 | 100 | 120 |
| Powder of motor | KW | 2.2 | 3 | 4 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 | 11 | 15 | 18.5 | 18.5 |
| Overall size | L-R | mm | 600 | 620 | 620 | 650 | 750 | 790 | 800 | 1000 | 1100 | 1200 | 1200 | 1320 |
| F-B | mm | 800 | 1080 | 1100 | 1180 | 1230 | 1300 | 1340 | 1450 | 1550 | 1650 | 1700 | 2000 |
| Height above the floor | mm | 1700 | 1770 | 1880 | 2100 | 2150 | 2400 | 2500 | 2800 | 2950 | 3000 | 3120 | 3400 |
| Total weight | Kg | 450 | 700 | 800 | 1200 | 1600 | 2500 | 4000 | 5000 | 6800 | 8500 | 12000 | 16000 |
If you are staking, crimping, broaching, notching, or inserting,
these presses offer ease of access and can be equipped with data
collection, force vs. distance monitoring, index units, speed
control, and various electronic packages.
Machine highlight: High degree of automation, high stability,
energy saving and low noise
MEILI C-type Hydraulic Press is a kind of multifunctional machine
which has strong generality. It is suitable for the press fitting
of shaft components and axle sleeve parts as well as the movements
of coining and overprinting. It can also be used to press powder
and plastic products which the requirements are not strict. At the
same time, it mainly applies to the fields of machine tool,
engineering machinery, electrical components, bearings, washing
machine, automobile parts and motor components. It can even be used
as assembly line. The pressure, stroke, and time of pressure
maintaining can be regulated.
Features:
• This structure of this C Frame press looks like letter "C" and
all parts and installed in the machine body which facilitate easy
and safe operation.
• C Frame high strength structure design with three sides open for
easy material loading and product unloading as well as easy
connecting with other corollary equipment.
• This C Frame hydraulic punching press can be tailor made to meet
different application requirements.
Options:
• Die Change/Die Clamp Device;
• Upper Ejector, Bottom Ejector;
• Punch Head; Upper Table;
• Servo System
